Cerberus MI
Modular Integration
The ultimate tactical and lethal small unmanned aircraft system (sUAS)
Designed from the outset to incorporate robustness to weapon recoil and the intrinsic ability to aim a lethal payload without a weapon gimbal, Cerberus MI provides the warfighter an aerial robotic system equipped with modular kinetic and non-kinetic payloads.
Tactical units require a lethal sUAS that can operate in complex environments, with the capability of delivering organic strikes. Cerberus MI operates using standard military inventory ammunition and can be deployed by a single operator, whilst remaining man packable. When other ISR assets detect targets during dismounted or mounted operations, Cerberus MI would provide a precise engagement and reduce the reliance on large Close Air Support (CAS) assets, potentially minimising collateral damage.
55 km/h
Max Speed
With max payload
22 kg
MTOW
Group 2 UAS
5 kg
Max Payload
42 mins
Max Flight Time
No payload
Rapid into-action time
Removeable arms, folding landing gears, and modular payload bay to facilitate quick into-action
AiTR & Tracking
AI Target Recognition and Tracking onboard to support rapid engagement and lawful targeting
Low cost per shot
Re-usable and re-loadable with lethal or non-lethal payload configurations
Ruggedized Connectors
MIL-SPEC connectors for improved reliability and recoil survivability
Technical Specifications
| UAS Weight (no payload) | 17.5 kg / 38.5 lbs |
| Max payload weight | 5 kg / 11 lbs |
| Maximum Take-Off Weight (MTOW) | 22 kg / 48.5 lbs |
| Range | 3 - 5 km (GCS to UAS LOS) |
|
Flight Endurance No payload MTOW Optimum Cruise Speed |
42 minutes 32 minutes 54 minutes |
Max Flight Speed (horizontal) | 30 kts / 15 m/s |
| Wind Gust Limits | 20 kts / 10 m/s (Beaufort Wind Scale Level 5) |
| Typical Operating Altitude | 400 ft |
| Operational Temperature |
Min: 14°F / -10°C Max: 104°F / 40°C |
| Ingress Protection (IP) Rating | IP54 (electronics box) |
| Data links | Silvus StreamCaster Dual band S Band (235) or Federal C1 / Doodle Labs Mesh Rider 2.4GHz |
| Compute Core | NVIDIA Jetson |
| Sensor Package | EO & IR Optical Sensors and Laser Range Finder |
| Deployment Time (Unpack-to-Fly, kinetic payload) | <7 minutes (unpack, assemble, mount and load HAVOC, GNSS acquired) |
| Launch/Recovery Method | VTOL |
|
Dimensions (Length x Width x Height) Assembled Disassembled |
1837 mm x 2053 mm x 435 mm / 72.3” x 80.8” x 17.1” 703 mm x 477 mm x 267 mm / 27.6” x 18.7” x 10.5” |
| Ground Control Station | UXV Technologies SRoC |
Expression of Interest
If you would like to learn more about the Cerberus MI, please get in touch.
